elm-sketch-importer

Takes a Sketch file, and generates Elm out of it. This is particularly useful if you want to quickly export some part of a design into Elm.

This is a work in progress. PRs are welcome!

Installation

We use elm-format in order to format the output correctly. It is recommeneded that you have this installed globally, via

npm install -g elm-format

Installing the elm-sketch-importer itself is pretty easy.

npm install -g elm-sketch-importer

Usage

Usage: [sketchfile]

Options:
  -h, --help         Show help                                         [boolean]
  -o, --output       Configure the output directory for generated Elm
                                                          [default: "generated"]
  --ef, --elmformat  Specify the location of the elm-format binary
                                                         [default: "elm-format"]

Examples:
  elm-sketch-importer ~/Documents/example.sketch

Support

Layers

Shapes and rects

Feature	Supported?
Rectangles	:white_check_mark:
Layer positions	:white_check_mark:
Layer sizes	:white_check_mark:
Multiple layers	:white_check_mark:
Fills	:white_check_mark:
Border	:warning:
Border color	:warning:
Colored fills	:white_check_mark:
Other shapes	:warning:
Groups	:warning:
Slices	:warning:
Images	:white_check_mark:

Text

Right now, long text is not correctly exported. This is down to the fact that BPLists are a little difficult to parse in Elm. Support will be coming soon, once I've finished the parser!

Feature	Supported?
Short text	:white_check_mark:
Long text	:warning:
Horizional/vertical flips	:white_check_mark:
Position	:white_check_mark:
Size	:warning:
Color	:warning:
Font	:warning:

Roadmap

This roadmap intends to be a rough priority list. No dates nor time are fixed -- but the more PRs to help, the faster things get done :)

Before 1.0

Relative layout instead of fixed pixels
Full support for importing Sketch files
- Make sure that no features remain unsupported

After 1.0

Export views to Sketch

Misc

Generating elm-css or style-element based views
