leaflet-sidebar-v2
A responsive sidebar for Leaflet. A fork of sidebar-v2 that only contains the necessary ingredients for use in Leaflet and provides enhanced functionality.
Hint: There's a Angular wrapper available at https://github.com/runette/ngx-leaflet-sidebar
Why the Fork?
- JS API for panel modification
- "autopan" feature, moving the map content next to the sidebar content
- only supports leaflet (0.x and 1.x) to maintain a smaller codebase and support more features
- compatibility with bootstrap (no generic
.sidebarclass) - provide a npm package
leaflet-sidebar-v2withmainandstylefields inpackage.json
Examples
in examples folder, available live at https://noerw.github.io/leaflet-sidebar-v2/examples
Usage
API
leaflet-sidebar-v2 provides a simple API to dynamically modify the sidebar. All functions may be chained.
creation
The parameters object is fully optional. The default values are shown:
var sidebar = L.control.sidebar({
autopan: false, // whether to maintain the centered map point when opening the sidebar
closeButton: true, // whether t add a close button to the panes
container: 'sidebar', // the DOM container or #ID of a predefined sidebar container that should be used
position: 'left', // left or right
}).addTo(map);modification
/* add a new panel */
var panelContent = {
id: 'userinfo', // UID, used to access the panel
tab: '<i class="fa fa-gear"></i>', // content can be passed as HTML string,
pane: someDomNode.innerHTML, // DOM elements can be passed, too
title: 'Your Profile', // an optional pane header
position: 'bottom' // optional vertical alignment, defaults to 'top'
};
sidebar.addPanel(panelContent);
/* add an external link */
sidebar.addPanel({
id: 'ghlink',
tab: '<i class="fa fa-github"></i>',
button: 'https://github.com/noerw/leaflet-sidebar-v2',
});
/* add a button with click listener */
sidebar.addPanel({
id: 'click',
tab: '<i class="fa fa-info"></i>',
button: function (event) { console.log(event); }
});
/* remove a panel */
sidebar.removePanel('userinfo');
/* en- / disable a panel */
sidebar.disablePanel('userinfo');
sidebar.enablePanel('userinfo');open / close / show content
/* open a panel */
sidebar.open('userinfo');
/* close the sidebar */
sidebar.close();remove sidebar
/* remove the sidebar (keeping the sidebar container) */
sidebar.remove();
sidebar.removeFrom(map); // leaflet 0.x
/* to clear the sidebar state, remove the container reference */
sidebar._container = nullmarkup
If you use the sidebar with static content only, you can predefine content in HTML:
<div id="sidebar" class="leaflet-sidebar collapsed">
<!-- Nav tabs -->
<div class="leaflet-sidebar-tabs">
<ul role="tablist"> <!-- top aligned tabs -->
<li><a href="#home" role="tab"><i class="fa fa-bars"></i></a></li>
<li class="disabled"><a href="#messages" role="tab"><i class="fa fa-envelope"></i></a></li>
<li><a href="#profile" role="tab"><i class="fa fa-user"></i></a></li>
</ul>
<ul role="tablist"> <!-- bottom aligned tabs -->
<li><a href="#settings" role="tab"><i class="fa fa-gear"></i></a></li>
</ul>
</div>
<!-- Tab panes -->
<div class="leaflet-sidebar-content">
<div class="leaflet-sidebar-pane" id="home">
<h1 class="leaflet-sidebar-header">
sidebar-v2
<div class="leaflet-sidebar-close"><i class="fa fa-caret-left"></i></div>
</h1>
<p>A responsive sidebar for mapping libraries</p>
</div>
<div class="leaflet-sidebar-pane" id="messages">
<h1 class="leaflet-sidebar-header">Messages<div class="leaflet-sidebar-close"><i class="fa fa-caret-left"></i></div></h1>
</div>
<div class="leaflet-sidebar-pane" id="profile">
<h1 class="leaflet-sidebar-header">Profile<div class="leaflet-sidebar-close"><i class="fa fa-caret-left"></i></div></h1>
</div>
</div>
</div>You still need to initialize the sidebar (see API.creation)
Events
The sidebar fires 3 types of events:
opening, closing, and content.
The latter has a payload including the id of the activated content div.
You can listen for them like this:
sidebar.on('content', function(e) {
// e.id contains the id of the opened panel
})License
leaflet-sidebar-v2 is free software, and may be redistributed under the MIT license.
