protomaps-leaflet

Vector tile rendering and labeling for Leaflet.

This project is a complete vector tile renderer - including quality label layout - in as simple as possible of an implementation. It's an alternative to renderers like MapLibre GL JS in a fraction of the size.

New projects starting from scratch should probably use MapLibre GL, but this library is useful as a drop-in replacement for raster basemaps in Leaflet, either using the Protomaps API or PMTiles on your own storage.

Features

• Render interactive slippy maps with Leaflet integration
• Supports variable web fonts with multiple weights and italics in a single font file
• Can read normal Z/X/Y tile URLs or offline, static-hosted tile archives in PMTiles format
• Full out-of-the-box support for right-to-left and Indic/Brahmic writing systems
• Configurable via plain JavaScript
• (Advanced) Extensible API for defining your own symbolizers

See the docs on what protomaps-leaflet is, what protomaps-leaflet is not

Demos

• Simple Leaflet demo
• Satellite + labels demo
• GeoJSON between basemap and labels demo
• Map inset
• Custom fonts

How to use

<script src="https://unpkg.com/protomaps-leaflet@4.0.1/dist/protomaps-leaflet.js"></script>
<script>
    const map = L.map('map')
    var layer = protomapsL.leafletLayer({url:'FILE.pmtiles OR ENDPOINT/{z}/{x}/{y}.mvt',flavor:"light",lang:"en"})
    layer.addTo(map)
</script>

See Also

• Tangram
• KothicJS
• Leaflet.VectorGrid

5.0.1

• Update pmtiles dependency by @ycouble [#194]

5.0.0

This is a breaking major version change.

• Now only works with the protomaps basemap tileset v4.0 and above. [#177]
• visualize the landcover layer in the light and dark flavors.
• replace theme option with flavor in frontends.
• Add a lang option to frontends to change the label language. [#157]
• depend on the @protomaps/basemaps package for flavor definitions.

4.1.0

• clarify types of LeafletLayerOptions and leafletLayer via @jwasilgeo [#179]

4.0.1

• Fix left-shift numerical problem in static frontend projection via @saranrapjs [#171]

4.0.0

• switch to tsup for generating ESM, CJS and IIFE modules [#158, #161, #162].
• should fix import issues related to typescript.
• IIFE script name changed from protomaps-leaflet.min.js to protomaps-leaflet.js
• generate ESM and CJS builds unbundled. iife is still unbundled.
• remove use of default exports: theme.ts exports theme
• bump internal dependencies.

3.1.2

• Fix pmtiles URL detection on relative paths [#152]

3.1.1

• Detect pmtiles URLs by using URL parsing, which handles query parameters [#147]

3.1.0

• add queryTileFeaturesDebug back in for basic interactions (You should use MapLibre if you want interactivity)

3.0.0

• Unexport PMTiles because you shouldn't be depending on the one bundled in this library.
• Bump pmtiles dependency to v3.x
• package.json defaults to ES6.
• remove CubicBezier function as no longer used.

2.0.0

Major version 2.0 aggressively reduces the scope of this rendering library.

This library re-focuses on being a Leaflet plugin for vector tile basemaps, i.e. "Mapnik in the browser"

• All user interaction features are removed. Every mapping application with clickable features should use MapLibre GL JS.

• MapLibre JSON style compatibility is removed. The surface area of the JSON style is too large to maintain for real-world use cases, and styles written for MapLibre perform poorly with this library.

• Programmatic shading and extra basemap styles are removed. This library's default style aligns with the 5 MapLibre styles developed in protomaps/basemaps.

• levelDiff is no longer configurable and defaults to 1 to match MapLibre GL.

• consistent camelCase naming e.g. paint_rules -> paintRules

• You must pass one of the default basemap themes light, dark, white, black, grayscale. remove dark and shade options.

• Remove WebKit vertex count workaround.

• remove PolygonLabelSymbolizer as it is not accurate for tiled rendering.

• maxDataZoom defaults to 15.

• Use Protomaps basemap tileset v3 instead of v2.

• remove setDefaultStyle method.

• remove multi-language language1, language2: frontends take a single language parameter.

1.24.2

• Continue internal refactors in preparation of 2.0.0 major revision.

1.24.1

• Apply linting rules; fix scoping and equality problems caught by linter.

1.24.0

• library renamed from protomaps to protomaps-leaflet, including npm package.

1.23

• bump pmtiles to 2.6.1.

1.22

• fix type of multiple Sources passed into leaflet layer or static map.

1.21

• support pmtiles v3.

1.20.2

• missing tiles in PMTiles archive do not show a browser error

1.20.1

• Fix stroking of circle symbolizer
• Fix static map drawCanvasBounds and drawContextBounds coordinate order

1.20.0

• Fix labeling-across-tiles bug introduced in 1.19.0
• Support for vector PMTiles with compression

1.19.0

• Multiple vector tile sources in a single layer

1.18.2

• Fix missing last stroke of PolygonSymbolizer
• make css-font-loading-module a dependency for types to be findable

1.18.0

• Sprites module formerly under protosprites package merged into this project

1.16.0

• Set canvas size to 0,0 before garbage collection, workaround for Safari

1.15.0

• Type improvements for Symbolizers, thanks nf-s
• add additional TextTransforms
• LineLabelSymbolizer features, step interpolation features, label deduplication

1.14.0

• Label repetition for lines
• Limit label repetition when overzooming

1.13.0

• PolygonSymbolizer has stroke and width for efficient outlines.
• maxLineChars line-breaking can be a function.

1.12.0

• Static takes same basic options as leaflet frontend.

1.10.0

• backgroundColor option for leaflet or static map.

1.9.0

• Center text justification only in the case of CenterdSymbolizer
• TextSymbolizer label_props can be a function
• LineSymbolizer lineJoin and lineCap attributes

1.8.0

• add Padding generic label symbolizer

1.7.0

• TextSymbolizer attributes: lineHeight in em, letterSpacing in px
• add linear and step shortcut functions for zoom-based styling

1.6.0

• add removeInspector

1.5.0

• levelDiff option to set ratio of display tiles to data tiles.

1.4.0

• Feature picking more accurate; uses distance-to-line and point-in-polygon.
• xray option to show all layers.

1.3.0

• addInspector to click on features and show an information popup.

1.2.0

• Label symbolizers for point and polygon features take the same set of attributes for text display.
• Add maxLineChars to define line breaking by maximum code units

1.1.0

PickedFeature in queryFeatures returns object with LayerName and feature.

1.0.0

• Most color and numerical Symbolizer attributes can now be treated as evaluated properties, with parameters (zoom:number,feature:Feature)
• Rule filters parameters changed from (properties:any) to (zoom:number,feature:Feature) to enable filtering on zoom level and geom_type.
• Feature.properties renamed to Feature.props for brevity
• Internal PaintSymbolizer.draw signature now takes zoom as third parameter.
• properties for defining fallbacks for text in label Symbolizers renamed to label_props e.g. ["name:en","name"]
